Side view camera

N1 is widely used in trucks, buses, vans and other vehicles. Installed on the side of the vehicle, with 360 DEG; Rotate to facilitate installation. The product has excellent night vision function, 1p68 waterproof, wide angle, clear image qua

Product description

parameter

N1 is widely used in trucks, buses, vans and other vehicles. Installed on the side of the vehicle, with 360 DEG; Rotate to facilitate installation. The product has excellent night vision function, 1p68 waterproof, wide angle, clear image quality and so on. The product is a combination of metal and plastic shell, which is not easy to be damaged by foreign objects

上一篇：Cab camera ←

下一篇：Driver's camera →

Items	Parameters
Sensor	1/2.9 inch COMS 1058/2053/225sensor
Signal format	Analog or AHD
Video Resolution	PAL/NTSC : 1920*1080
Frame rate	PAL:25fpcs, NTSC:30fps
Minimum Illumination	color：0.01Lux@（F1.2，AGC ON）
Minimum Illumination	Black & White：0.001Lux@（F1.2，AGC ON）
Synchronous Mode	inter-sync
Shutter	1/50(1/60) seconds to 1/10,000 seconds
Noise-signal Ratio	>48dB
Temperature and Humidity	- 20 ℃ ~ 60 ℃, humidity is less than 90% (no condensation)
Consumption	<5W
Power Supply	DC12V±20%
Field Angle(D/H/V)	170°/120°/95°
Mic	NO
IR	LED
Connector	4Pin Navigation Port
Lens number	one
Cable	High temperature resistant and shielded cable
Water-proof	IP-68
